TP-2-228

House kit cost:
$50 996
*The indicated price is not a public offer. Please check the current price with our managers.
Визуализация
Визуализация
Визуализация
Визуализация
Визуализация

Standard project of a two-story house made of SIP panels TP-2-228 includes a spacious kitchen-dining-living room of 56 m2 with access to a terrace of 55 m2. The living room features a “second light” with a ceiling height of 6.5 m. Another feature of the project is the master bedroom of 15 m2 with its own separate walk-in closet of 5 m2, a bathroom of 6.0 m2, and its own separate balcony of 15 m2. In addition to the master bedroom, the house also has three bedrooms of 15 m2, 12 m2, 12 m2, and two bathrooms of 6 m2 and 4 m2 for these three bedrooms. One of these three bedrooms has its own balcony of 5.7 m2. A technical room for locating engineering equipment of 6 m2 is also provided, where a gas boiler room can be arranged in accordance with the requirements of the legislation of the Russian Federation. The area of the entrance hall is 4 m2, and the entrance hall also has its own separate wardrobe of 3.5 m2. The area of the porch with a canopy is 5.7 m2. The well-thought-out layout with a master bedroom, with a second light in the living room, and with a wardrobe in the entrance hall allows for very comfortable living in the house and meets all modern requirements. This project can undoubtedly be classified as comfort-class housing and above!

Object Specifications:
  • Number of Floors
    2
  • Building Area, m²
    228
  • Length, m
    11.9
  • Width, m
    11.7
  • House height, m
    7.8
  • Total Area, m²
    163
  • Floor-to-ceiling height, m
    2.7
  • Number of Rooms
    5
  • Number of Bathrooms
    3
  • Number of windows, pcs
    26
  • Glazing area, m2
    57
  • Facade area, m2
    278
  • Roof pitch angle, °
    22
  • Roof type
    Multi-pitched
  • Roof area, m2
    155
  • Number of entrance doors, pcs
    2
  • Production time, days
    from 25
  • Volume, m3
    127
  • Weight, tons
    47
  • Delivery terms
    Pickup from warehouse (EXW)
  • Loading and packaging
    Included
  • Master Bedroom
    Yes
Architectural elements
  • Porch
    5.7 m²
  • Terrace
    55 m²
  • Balcony
    5.7 m²
  • Balcony
    15 m²
Layout solutions
1st Floor
Проект двухэтажного дома из сип панелей
1.
Living Room 29 m²
2.
Dining Room 15 m²
3.
Kitchen 12 m²
4.
Bedroom 15 m²
5.
Bathroom 4 m²
6.
Technical Room 6 m²
7.
Walk-in Closet 3.5 m²
8.
Entrance hall 4 m2
9.
Porch 5.7 m²
10.
Terrace 55 m²
2nd Floor
Проект двухэтажного дома из сип панелей
1.
Master Bedroom 15 m²
2.
Master walk-in closet 5 m²
3.
Master Bathroom 6 m²
4.
Balcony 15 m²
5.
Bedroom 12 m²
6.
Bedroom 12 m²
7.
Balcony 5.7 m²
8.
Bathroom 7 m²
9.
Hall 17 m²
Order a panel-frame SIP house kit based on a ready-made standard design
Place an Order
Something does not fit? No problem. Contact us, and we will create a project for you absolutely free! Any changes can be made to the house configuration and layout with the corresponding budget adjustment.
Modify the Project
House kit
Standard project
$722
Grillage made of kiln-dried planed timber. Ground floor structure made of VIRMAK SIP panels with CSP and EPS.
$12 130
Exterior walls made of VIRMAK® SIP panels with cement-bonded particle board and EPS. Interior partitions are frame structures made of kiln-dried planed timber.
$29 366
Intermediate floor slab made of I-beams (or joists)
$8 778
Total for the house kit
$50 996
Additional materials and work (estimated prices for planning and understanding the construction budget)
bs_object_specs
Foundation
SVSN screw pile (blade Ø300 mm, shaft Ø108 mm, length 2500 mm)
$1 995
House kit installation
House kit installation
$22 344
Roof and roofing with installation
Стропильная система из пиломатериала
$10 850
Roofing - metal tile 0.5 mm, polyester 25 µm, Zn 100-140 g/m² and installation. Soft shingles plus 8%
$5 425
PVC windows and doors (if included in the project)
PVC windows and doors (if included in the project)
$7 980
Total for the house kit with installation*
$99 590
What can you save money on?
You should not save on the house kit
0%
Order foundation installation directly from a specialized contractor
30%-40%
Purchase a house kit and install it on your own with the help of our remote author’s (technical) supervision or with installation supervision from a VIRMAK representative
30%-40%
Purchase the house kit, and we will provide a certified crew
30%-40%
Purchase the house kit based on a standard design rather than a custom design
30%-40%

Project Implementation Examples

Important:

The price of the house kit does not include the porch and terrace. Please check the price with our managers.
The information in this project and the list of materials used are relevant for Krasnodar Krai.

Please check the construction cost for other regions of the Russian Federation.

 For any questions, please contact us using the contact details listed on the website (phone numbers, email, etc.).

For a more accurate preliminary estimate, indicate the district (address) of the future construction.

Need a consultation? Call right now or leave a request using the «contact button».

Minor price changes may be caused by: slopes on the site, difficult access roads, lack of electrical power, etc.

All projects posted on the website are schematic and can serve as initial material for creating a project according to your wishes and recommendations.
